| Moderated by: Greg Fletcher | Page: 1 2   |
|
|||||||||||||
| FUEL PUMP | Rating:
|
| Author | Post |
|---|
| Posted: 05-10-2007 04:42 am |
|
1st Post |
|
Ian Brooks Member
|
Bought a rolling chassis & will be doing a total restore with the 2.2 upgrade & the toyota 5 speed.Was wandering what fuel pump would be the best one to get .Have the dellorto 45,s.if that helps.Are there some that are more reliable than other,s.Thanks ,Ian
|
||||||||||||||
| |||||||||||||||
| Posted: 05-10-2007 02:30 pm |
|
2nd Post |
|
Judson Manning Member
|
Ian, After the cheap pump I bought 10 years ago from Autozone finally died last month, I upgraded to a Holly 'red' fuel pump available at most hot-rod shops. I'll post some pics of the pump installation, pressure regulator and braided lines later. This is a very similar set-up to Ron Earp's ITS car and can be considered somewhat 'overkill' as my old pump did just fine during in my limited racing adventures. The basic upgrade from the original pump is a solid-state version that eliminates the troublesome points. Personally, I went through 3 Lucas pumps and refuse to try them again, others have had fantastic luck. Generally speaking, you can adapt virtually any off-the-shelf pump designed for a mid-70s MGB to work with JH (that's how I ended-up with the above mentioned Autozone pump when Lucas#3 failed). The only spec you need to keep in mind is fuel pressure should be 1-4psi. Judson
|
|||||||||||||
| ||||||||||||||
| Posted: 05-10-2007 02:44 pm |
|
3rd Post |
|
Ian Brooks Member
|
Thanks for the reply Judson,would any more than 4psi start blowing seals ,flooding or something.Ian
|
||||||||||||||
| |||||||||||||||
| Posted: 05-10-2007 04:53 pm |
|
4th Post |
|
Greg Fletcher Administrator
|
2.5 - 3 pounds is recommended on Strombergs and Dellortos. The replacement SU pump with electronic head is a cool unit.
|
|||||||||||||
| ||||||||||||||
| Posted: 05-10-2007 05:10 pm |
|
5th Post |
|
Mitch Ware Member
|
I went the expensive electronic SU fuel pump when I restored my car. It crapped out after two years. Mitch Ware #19670
|
||||||||||||||
| |||||||||||||||
| Posted: 05-10-2007 05:19 pm |
|
6th Post |
|
Greg Fletcher Administrator
|
That's too bad, I've had good luck with the electronic ones. Did you try to repair the unit or know what caused the failure?
|
|||||||||||||
| ||||||||||||||
| Posted: 05-10-2007 07:33 pm |
|
7th Post |
|
Mitch Ware Member
|
Not sure what caused the failure. The symptom wasn't that it didn't pump at all, it just didn't pump very much. The car would idle all day long, but try and drive it and it would starve for fuel after about a mile. I could push the clutch in and coast, this would allow the pump to catch up, then I could drive another mile. I do have an inline filter both before and after the fuel pump, and the filter was not getting plugged up with debris, so I didn't think debris was the problem. I think I still have the pump in my garage somewhere. I replaced it with the non-electronic SU and it has been working fine for two years. Mitch Ware #19670
|
||||||||||||||
| |||||||||||||||
| Posted: 05-10-2007 10:50 pm |
|
8th Post |
|
Scott Robinson Member
|
They don't get mentioned on here often, but I have five + years of trouble free road and track usage on (and can recommend) a Carter (universal model) that offers the ideal high volume flow at 2.5 -3 psi. Only thing it doesn't do is click!
|
|||||||||||||
| ||||||||||||||
| Posted: 05-14-2007 08:59 pm |
|
9th Post |
|
j23mau Member
|
What is the model number scott? I need to replace one and don't have the original now anyways so staying true to form is no big deal to me. Thanks----Jeremy
|
||||||||||||||
| |||||||||||||||
| Posted: 05-16-2007 04:42 am |
|
10th Post |
|
Scott Robinson Member
|
The Carter pump I have is P/N 152875. Can't find the paperwork, but that's what the label says. Scott
|
|||||||||||||
| ||||||||||||||
| Posted: 05-16-2007 04:04 pm |
|
11th Post |
|
Judson Manning Member
|
Holley Fuel Pump installation pics. I still need to install and plumb a 'real' fuel filter in place of the glass filter and rubber lines. Another project for another day... Attachment: FuelPump1.jpg (Downloaded 73 times) Last edited on 05-16-2007 04:15 pm by Judson Manning |
||||||||||||||
| |||||||||||||||
| Posted: 05-16-2007 04:13 pm |
|
12th Post |
|
Judson Manning Member
|
View of engine compartment showing fuel pressure regulator (bottom of screen) and fuel pressure gauge. Regulator is set at 2-3psi as the Holley 'red' pump is factory set at 7psi and tends to overwhelm the floats and floods the engine. Hard tubing piped directly to the regulator and AN6 braided line to feed the carburators. Attachment: FuelPump2.jpg (Downloaded 77 times)
|
|||||||||||||
| ||||||||||||||
| Posted: 05-16-2007 06:45 pm |
|
13th Post |
|
j23mau Member
|
Judson, What is the reason for the fuel line going into the air filters? My guess is that if you use the original fuel pump or similar you may not need it. But I will be putting Dells on soon and the more information I have the better. Thanks Jeremy
|
||||||||||||||
| |||||||||||||||
| Posted: 05-16-2007 08:20 pm |
|
14th Post |
|
Judson Manning Member
|
Jeremy, The fuel line is not routed to the air-filters. Yes, there are a myriad of braided hoses in my engine bay, but that is the crankcase ventillation hose going to the air-filters. That line comes from the windshield wiper fluid resivoir which was converted to a catch-can. The fuel line can be seen at the bottom of the picture attaching to the pressure gauge, then to the pressure regulator. What is not visible is the hard line that is plumbed to the bottom of the regulator going back to the pump. As I mentioned in my initial posting this is somewhat of an 'overkill' solution. The only major difference between using the Holley pump and a Lucas-type pump is the need for the regulator. All the hard & braided lines are there primarly for safety when I go racing. The technical & safety inspectors tend not to trust British cars, much less 30 year-old plumbing. Judson Last edited on 05-16-2007 08:25 pm by Judson Manning |
|||||||||||||
| ||||||||||||||
| Posted: 05-16-2007 08:41 pm |
|
15th Post |
|
Greg Fletcher Administrator
|
I think this was the last guy that routed his fuel line to the air filters (or maybe it was the fuel line to the distributor, I can't remember now)-
|
||||||||||||||
| |||||||||||||||
| Posted: 05-17-2007 04:17 am |
|
16th Post |
|
Jensen Healey Super Moderator
|
Judson, very sorry to see your car in flames. Next time run the heater hose to the air filters.
|
|||||||||||||
| ||||||||||||||
| Posted: 05-17-2007 02:52 pm |
|
17th Post |
|
Judson Manning Member
|
ROTFLMAO! Better yet, I was thinking of routing the fuel pump through the Halon fire suppression system so it sprayed raw fuel ON the engine and INTO the passanger compartment when activated!
|
||||||||||||||
| |||||||||||||||
| Posted: 05-24-2007 11:48 pm |
|
18th Post |
|
timeforwalkies Member
|
Talk about routing, check this out. This car was for sale on Ebay two weeks ago. Any thoughts? I did look at this car and while sweet in the photos......well, I didn't buy it. Not that it was bad, just to much bling and an effort to remove. Attachment: JH FUEL SET UP.JPG (Downloaded 134 times)
|
|||||||||||||
| ||||||||||||||
| Posted: 05-25-2007 01:22 am |
|
19th Post |
|
Joel Member
|
i saw that too! what the heck? just what i want - my fuel pump exposed to the elements and being hit! is that a stock rear end? Last edited on 05-25-2007 01:23 am by Joel |
||||||||||||||
| |||||||||||||||
| Posted: 05-25-2007 01:31 am |
|
20th Post |
|
Greg Fletcher Administrator
|
I think the idea is- you get rear-ended, fuel sprays all over the place, lights up in a manner similar to the photo above, make insurance claim and buy electric car.
|
|||||||||||||
| ||||||||||||||
